Executive Summary

A vapor–liquid separator is a device used to separate a vapor–liquid mixture into its constituent phases. It can be a vertical or horizontal vessel, and can act as a 2-phase or 3-phase separator. The separator is only effective as long as there is a vapor space inside the chamber. The separator can fail if either the mixed inlet is overwhelmed with supply material, or the liquid drain is unable to handle the volume of liquid being collected.

In chemical engineering, a vapor–liquid separator is a crucial component in various industrial processes. It is used to separate a vapor–liquid mixture into its constituent phases, allowing for the efficient processing and handling of the separated components. The separator can be designed to operate as a 2-phase or 3-phase separator, depending on the specific requirements of the application.

Architecture & Design

The architecture and design of a vapor–liquid separator are critical to its effective operation. The separator can be a vertical or horizontal vessel, and can be designed to operate as a 2-phase or 3-phase separator. The separator typically consists of an inlet diffuser, a mesh pad or mist mat, and a gas outlet. The inlet diffuser reduces the velocity and spreads the incoming mixture across the full cross-section of the vessel, while the mesh pad or mist mat aids separation and prevents liquid from being carried over with the vapor.

The gas outlet may itself be surrounded by a spinning mesh screen or grating, so that any liquid that does approach the outlet strikes the grating, is accelerated, and thrown away from the outlet. The vapor travels through the gas outlet at a design velocity which minimises the entrainment of any liquid droplets in the vapor as it exits the vessel. A vortex breaker on the liquid outlet prevents the formation of vortices and of vapor being drawn into the liquid outlet.

Performance & Thermal

The performance and thermal characteristics of a vapor–liquid separator are critical to its effective operation. The separator must be designed to operate within a specific temperature and pressure range, and must be able to handle the expected flow rates and compositions of the vapor–liquid mixture. The separator must also be designed to minimize the entrainment of liquid droplets in the vapor, and to prevent the formation of vortices and the drawing of vapor into the liquid outlet.

In low gravity environments, such as a space station, a common liquid separator will not function because gravity is not usable as a separation mechanism. In this case, centrifugal force needs to be utilised in a spinning centrifugal separator to drive liquid towards the outer edge of the chamber for removal. Gaseous components migrate towards the center.
